Digital Microscope Set KERN OBL 137T241

AED 13,040.00

Availability:In stock

SKU

LBX-KRN-2411

Explore precision with the OBL 137T241 Digital Microscope Set, featuring an infinity optical unit and Koehler illumination for superior clarity. This set includes a KERN ODC 241 tablet camera with 5-MP resolution, live image transfer, and measurement functions. Ideal for educational and laboratory use, it comes with a protective dust cover, eye cups, and multilingual instructions. Enhance your investigations with strong 3W-LED lighting, a focusable condenser, and comprehensive connectivity options including USB, HDMI, and WiFi.

BrandKern

More Information
Product Name	Digital Microscope Set KERN OBL 137T241
Weight	1.000000
Part No.	LBX-KRN-2411
Supplier Item Code	OBL 137T241
Input voltage power supply Max	100 - 240 V
Gross weight	10 kg
Total packaging weight	1772 g
Net weight	8 kg
Tube angle of inclination	30°
Illuminance	Transmitted light
Optical system	Infinity
Tube type	Trinocular

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Technical Data
Optical system	Infinity
Tube type	Trinocular
Ocular magnifications	10 x
Ocular visual field	20 mm
Standard objectives	4×, 10×, 40×, 100x
Lens quality	Infinity E-Plan
Nosepiece screw-in locations	4
Illuminance	Transmitted light
Illumination type transmitted light	LED
Illumination intensity transmitted light	3 W
Illumination type incident light	none
Condenser type	Abbe
Condenser Aperture	1.25
Condenser Mounting	fixed
Focusing mechanism	coaxial coarse and fine drive
Fine drive minimum	0.002 mm
Display type	LCD touch
Display screen size	9.7"
MCU Details	Quad Core Cortex-A17; 1.8 GHz
Display resolution	2048×1536
Camera - Sensor type	Sony CMOS
Camera - Colour depth	Colour
Camera - Sensor size	1/2.8”
Camera - Resolution	5 MP
Interfaces	WiFi standard, USB 2.0, HDMI, MicroSD card slot
Camera - Framerate	30 fps
C-Mount magnification	0.5 x
Dimension (W×D×H)	394×185×450 mm
