| Product Name | Digital Microscope Set KERN OBL 137T241 |
|---|---|
| Weight | 1.000000 |
| Part No. | LBX-KRN-2411 |
| Supplier Item Code | OBL 137T241 |
| Input voltage power supply Max | 100 - 240 V |
| Gross weight | 10 kg |
| Total packaging weight | 1772 g |
| Net weight | 8 kg |
| Tube angle of inclination | 30° |
| Illuminance | Transmitted light |
| Optical system | Infinity |
| Technical Data | |
|---|---|
| Optical system | Infinity |
| Tube type | Trinocular |
| Ocular magnifications | 10 x |
| Ocular visual field | 20 mm |
| Standard objectives | 4×, 10×, 40×, 100x |
| Lens quality | Infinity E-Plan |
| Nosepiece screw-in locations | 4 |
| Illuminance | Transmitted light |
| Illumination type transmitted light | LED |
| Illumination intensity transmitted light | 3 W |
| Illumination type incident light | none |
| Condenser type | Abbe |
| Condenser Aperture | 1.25 |
| Condenser Mounting | fixed |
| Focusing mechanism | coaxial coarse and fine drive |
| Fine drive minimum | 0.002 mm |
| Display type | LCD touch |
| Display screen size | 9.7" |
| MCU Details | Quad Core Cortex-A17; 1.8 GHz |
| Display resolution | 2048×1536 |
| Camera - Sensor type | Sony CMOS |
| Camera - Colour depth | Colour |
| Camera - Sensor size | 1/2.8” |
| Camera - Resolution | 5 MP |
| Interfaces | WiFi standard, USB 2.0, HDMI, MicroSD card slot |
| Camera - Framerate | 30 fps |
| C-Mount magnification | 0.5 x |
| Dimension (W×D×H) | 394×185×450 mm |
