Digital Microscope Set KERN OBN 132T241

AED 15,590.00

Availability:In stock

SKU

LBX-KRN-2417

Elevate your microscopy with the Digital Microscope Set 132T241, featuring an infinity optical unit and professional Koehler illumination. This OBN series microscope includes a mounted KERN ODC 241 tablet-camera for live image transfer and documentation. It boasts strong 3W-LED illumination, a large mechanical stage, and versatile imaging functions. Ideal for education and lab demonstrations, it supports USB, HDMI, and WiFi data transfer, and comes with a protective dust cover and multilingual instructions.

BrandKern

More Information
Product Name	Digital Microscope Set KERN OBN 132T241
Weight	1.000000
Part No.	LBX-KRN-2417
Supplier Item Code	OBN 132T241
Input voltage power supply Max	100 - 240 V
Gross weight	13 kg
Total packaging weight	2577 g
Net weight	10 kg
Tube angle of inclination	30°
Illuminance	Transmitted light
Optical system	Infinity
Tube type	Trinocular

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Technical Data
Optical system	Infinity
Tube type	Trinocular
Ocular magnifications	10 x
Ocular visual field	20 mm
Standard objectives	4×, 10×, 20×, 40×, 100×
Lens quality	Infinity Plan
Nosepiece screw-in locations	5
Illuminance	Transmitted light
Illumination type transmitted light	Halogen
Illumination intensity transmitted light	20 W
Illumination type incident light	None
Condenser type	Abbe
Kondensor - Aperture	1.25
Kondensor - Montage	Centerable
Focusing mechanism	Coaxial coarse and fine drive
Fine drive minimum	0.002 mm
Display type	LCD touch
Display screen size	9.7"
Display resolution	2048×1536
MCU Details	Quad Core Cortex-A17; 1.8 GHz
Camera - Sensor type	Sony CMOS
Camera - Colour depth	Colour
Camera - Sensor size	½.8”
Camera - Resolution	5 MP
Interfaces	WiFi standard, USB 2.0, HDMI, MicroSD card slot
Camera - Framerate	30 fps
C-Mount magnification	0.5 x
Dimension (W×D×H)	390×235×620 mm
