Inverted Microscope KERN OCM 168

AED 56,340.00

Availability:In stock

SKU

LBX-KRN-2446

Discover the advanced OCM 168 Inverted Fluorescence Microscope, designed for exceptional cell culture analysis. With ergonomic design, robust construction, and a 5W LED for bright field and Osram 5W-LED Epi fluorescence illumination, it ensures precise sample visualization. Equipped with a trinocular eyepiece tube, mechanical stage, and versatile accessories, it's perfect for research in cell and tissue cultures.

BrandKern

More Information
Product Name	Inverted Microscope KERN OCM 168
Weight	1.000000
Part No.	LBX-KRN-2446
Supplier Item Code	OCM 168
Input voltage power supply Max	100 V - 240 V AC 50/60 Hz 0,3 A
Gross weight	28 kg
Total packaging weight	5032 g
Net weight	22 kg
Tube angle of inclination	45°
Illuminance	Reflected light,Transmitted light
Optical system	Infinity
Tube type	Trinocular

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Technical Data
Optical system	Infinity
Tube type	Trinocular
Ocular magnifications	10 x
Ocular visual field	22 mm
Standard objectives	10×, 20×, 40×, PH 20×
Lens quality	Infinity Plan
Nosepiece screw-in locations	5
Illuminance	Reflected light, Transmitted light
Illumination type transmitted light	LED
Illumination intensity transmitted light	5 W
Illumination type incident light	LED
Illumination intensity incident light	5 W
Fluorescent unit	Ultraviolet, Violet, Blue, Green (LED)
Condenser type	Standard
Kondensor - Aperture	0.3
Kondensor - Montage	Fixed
Focusing mechanism	Coaxial coarse and fine drive
Fine drive minimum	0.002 mm
Dimension (W×D×H)	782×304×530 mm
