MEGATRON® MT-SHS In-Line Dispersers with Super High Shear

AED 109,587.00

Availability:In stock

Estimated Delivery: 8-10 Weeks

SKU

LBX-KIM-0457

The MEGATRON® MT-SHS In-Line Disperser delivers ultra-high shear rates of up to 300,000 s⁻¹ and rotor tip speeds of 65 m/s, achieving nano-sized particles or droplets. This innovative rotor-stator technology offers superior efficiency, customizable geometries, and seamless scalability to production machines.

BrandKinematica

More Information
Product Name	MEGATRON® MT-SHS In-Line Dispersers with Super High Shear
Weight	1.000000
Part No.	LBX-KIM-0457
Supplier Item Code	23022002

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Technical Data
Tip Speed	max. approx. 65 m/s
Motor	5.5 kW three-phase motor with frequency converter
Dimensions (LxWxH)	715 x 300 x 1020 mm
Speed Adjustment	Stepless with integrated controller and digital display
Speed Control	Stepless with integrated controller and digital display
Generators	SHS special rotor/stator geometry with finest tooth system
Recirculation Vessel	5.0 liter stainless steel vessel for the continuous phase, double-walled design with thermostat connections
Pipe Installation	Complete piping with the recirculation vessel
