Metallurgical Microscope KERN OKO 178

AED 12,663.00

Availability:In stock

SKU

LBX-KRN-2472

The KERN OKO 178 Metallurgical Microscope offers exceptional performance for testing metals and analyzing surfaces. Equipped with LED incident and transmitted illumination, a height-adjustable 1.25 Abbe condenser, and an open mechanical angle table, it ensures precise Köhler illumination. Includes a polarizing unit, dust cover, eye cups, and multilingual instructions. Ideal for metallurgy, material testing, and quality assurance. C-mount adapter needed for camera integration.

BrandKern

More Information
Product Name	Metallurgical Microscope KERN OKO 178
Weight	1.000000
Part No.	LBX-KRN-2472
Supplier Item Code	OKO 178
Input voltage power supply Max	100 V - 240 V AC 50/60 Hz 0,3 A
Gross weight	16 kg
Total packaging weight	4 kg
Net weight	12 kg
Tube angle of inclination	30°
Illuminance	Reflected light,Transmitted light
Optical system	Infinity
Tube type	Trinocular

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Optical System Technical Data
Optical system	Infinity
Tube type	Trinocular
Ocular magnifications	10 x
Ocular visual field	22 mm
Standard objectives	5×, 10×, 20×, 50×
Lens quality	Infinity semi apochromatic
Nosepiece screw-in locations	5
Illuminance	Reflected light, Transmitted light
Illumination type transmitted light	LED
Illumination intensity transmitted light	5 W
Illumination type incident light	LED
Illumination intensity incident light	5 W
Fluorescent unit	Ultraviolet, Violet, Blue, Green (LED)
Condensor type	Abbe
Kondensor-Apertur	1.25
Kondensor-Montage	Centerable
Focusing mechanism	Coaxial coarse and fine drive
Fine drive minimum	0.002 mm
Dimension (W×D×H)	550×200×460 mm
