Muffle Furnace

AED 8,276.00

Availability:In stock

Only %1 left

SKU

Muffle Furnace

FP111C/311C/511C Muffle Furnace – high-performance ceramic fiber furnace reaching 1150°C with ±1.5°C precision. Dual R-type thermocouple, iron-chromium-aluminum heater, and integrated PID+over-temp protection controller. Programmable 6-pattern operation with digital setting. Available in 1.5L–11.3L capacities, AC220V export specification. Ideal for ashing, sintering, and high-temperature material testing.

BrandYamato Scientific

More Information
Product Name	Muffle Furnace
Weight	1.000000

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Technical Data
Specification	FP111C	FP311C	FP511C
Operating temp. range	100~1150°C
Temp. control accuracy	±1.5°C (at 1150°C)
Time to max temp.	~80 min (from room temp)
Exterior	Cold-rolled steel plate, chemical-resistant baked coating
Furnace body	Ceramic fiber
Sensor	Dual R-type thermocouple
Heater material	Iron-chromium-aluminum alloy heating wire
Heater capacity	1.1kW	2.4kW	3.5kW
Exhaust port	φ20mm inner diameter, top
Cooling fan	Axial flow fan
Temp. control method	PID control (10-segment selectable)
Temp. setting/display	Digital setting / digital display
Over-temp protection	Integrated controller type
Over-temp protection setting	Digital setting
Operation modes	Constant value operation, program operation (6 patterns×30 steps×1 mode / 15 steps×2 modes / 10 steps×3 modes)
Additional functions	Calibration offset, power outage compensation, key lock
Timer	1min~99hr59min & 999hr50min, digital setting, auto-run, quick auto-stop
Safety devices	Self-diagnostic circuit (temp. sensor abnormality, auto over-temp prevention), over-temp protector, overcurrent leakage protection switch, key lock
Internal dims (W×D×H)	100×150×100mm	200×250×150mm	300×250×150mm
External dims (W×D×H)	376×405×516mm	446×505×566mm	507×505×626mm
Internal capacity	1.5L	7.5L	11.3L
Power source (50/60Hz)	AC220V, 5.5A	AC220V, 11A	AC220V, 16A
Weight	~24kg	~42kg	~48kg
Accessories	Exhaust port cover ×1
Optional — stand	ON30C	—	ON61C
Optional — other	Saggar (firing tray), exhaust device (AC220V), sample box, N2 introduction device (with flow meter), mini printer, recorder, combined alarm lamp (standby/running/fault), external communication (RS485), temp. output terminal (4-20mA), external alarm output terminal, time-up output terminal, centralized monitoring software
