External sealed cooling water circulation system NeoCool® Circulator

AED 10,886.00

Availability:In stock

SKU

LBX-YMT-0463

Yamato NeoCool® General-Purpose Cooling Water Circulator – versatile -20°C to 30°C closed-system chiller with 1,230W cooling capacity. One-touch rotating connector, magnetic front filter for easy cleaning, and optional secondary solvent trap. 15.5L stainless tank with 2A service outlet. Ideal for rotary evaporators, ICP-MS, and general lab equipment cooling.

BrandYamato Scientific

More Information
Product Name	External sealed cooling water circulation system NeoCool® Circulator
Weight	1.000000
Part No.	LBX-YMT-0463
Supplier Item Code	CF802

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Technical Data
Specification	CF802
Product code	221594
System	External closed-system circulation
Circulating water	Tap water (liquid temp ≥10°C) / Nybrine
Operating ambient temp.	5~35°C
Temp. control range	-20~30°C ¹²
Temp. control accuracy	JTM K05 ±1.0°C *³
Temp. fluctuation	JIS 3.0°C *³
Cooling capacity	~1,230W at liquid temp 10°C / ~560W at liquid temp -10°C *³
Temp. control method	Freezer ON-OFF control
Temp. sensor	Pt100Ω
Controller	White LED digital display, key input, min. digit 1°C
Refrigeration unit/refrigerant	Air-cooled, 650W, R407C
Circulation pump	Magnetic pump, 75/100W
Max flow rate (pump capacity), 50/60Hz	~12/14 L/min *⁴
Max head (pump capacity), 50/60Hz	~10.3/14.3m *⁴
External circulation connection port	One-touch connector (flexible rotating L-type), top rear, 1 system; connects to rigid hose φ10mm OD (flexible hose φ9mm ID with included hose nozzle); flow control valve on discharge port
Safety devices	Overcurrent leakage breaker, temp. sensor malfunction, temp. upper/lower limit warning, temp. upper/lower limit abnormality, chiller overload relay, fan motor protection, circulation pump protection, chiller protection delay timer, chiller high-voltage switch
Other functions	Drain hose, circulation port condensation drain hose, intake dust filter, cooling operation switch, circulation pump switch, calibration offset, power outage recovery (optional), 2A service outlet
Service outlet	2A
Tank material	Stainless steel
Tank capacity	~15.5L (liquid volume 14L)
Accessories	Hose nozzle ×2 (for flexible hose connection), condensation drain hose 1m (φ12mm ID) ×1, hose fixing clamps ×2
External dims (W×D×H)	340×370×838mm
Power capacity	AC100V, 15A (incl. service outlet)
Weight	43kg
