Precision Thermostat Fine Oven, 500℃, Forced Convection
AED 55,755.00
Availability:In stock
SKU
LBX-YMT-0335
Precision Thermostat – high-precision 500°C high-temperature oven ideal for drying, heat resistance, and lifespan testing. Features V-type controller, quadruple over-temperature protection, exhaust damper for rapid cooling, and RS485 communication. 216L capacity with self-diagnostic safety functions. Perfect for industrial and laboratory high-temperature testing applications.
BrandYamato Scientific
| Product Name | Precision Thermostat Fine Oven, 500℃, Forced Convection |
|---|---|
| Weight | 1.000000 |
| Part No. | LBX-YMT-0335 |
| Supplier Item Code | DH650Z |
| Technical Data | |
|---|---|
| Specification | DH650Z |
| Product code | 211155 |
| Method | Forced air circulation |
| Temp. control range | Room temp +10~500°C |
| Temp. control accuracy | ±0.5°C (at 500°C) JTM K05 |
| Temp. distribution accuracy | ±3°C (at 300°C), ±5°C (at 500°C) JTM K05 |
| Time to max temp. | ~60 minutes |
| Interior | Stainless steel sheet |
| Exterior | Electro-galvanized steel sheet, baked paint finish |
| Heater | Wire heater |
| Heater insulation | Rock wool, ceramic fiber, insulation blocks |
| Heater capacity | 7.8kW |
| Blower fan | Propeller fan |
| Blower motor | Capacitor motor |
| Exhaust port | φ80mm (with damper), 1 unit at rear |
| Heater control | SSR control |
| Sensor | K-type thermocouple (temp control + independent overheat protection) |
| Damper | Manual circulation/ventilation control |
| Safety devices | Self-diagnostic (sensor malfunction, heater wire break, SSR short-circuit, auto overheat, fan malfunction), key lock, independent tank overheat protection, independent heater room overheat protection, leakage circuit breaker, heater temp. fuse, alarm terminals |
| Other features | Variable wind speed, key lock, calibration offset, external alarm output, temp. output, time-up output, RS485 communication |
| Internal capacity | 216L |
| Shelf load capacity | ~30kg/piece |
| Shelf levels | 9 steps |
| Shelf pitch | 60mm |
| Shelf board accessory | 3× stainless steel wire shelves |
| Shelf bracket accessory | 6 sets |
| Internal dims (W×D×H) | 600×600×600mm |
| External dims (W×D×H) | 1350×950×1300mm |
| Power source | 3-phase AC200V, 23A |
| Breaker / supply capacity | 30A |
| Power cord | ~2m (power plug not included) |
| Weight | 250kg |
