Precision constant temperature water circulation device

AED 16,589.00

Availability:In stock

Only %1 left

Precision Constant Temperature Water Circulation Device (CFA311C/610C) — PID-controlled circulator with ±0.1°C precision across -10°C to 80°C. Air-cooled with R404A refrigerant, magnetic pump circulation, stainless steel heating tube, RS485 communication, and deviation correction. Comprehensive safety protection including over-temperature and dry-run prevention. Available in two cooling capacities.

BrandYamato Scientific

More Information
Product Name	Precision constant temperature water circulation device
Weight	1.000000

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Technical Data
Specification	CFA311C	CFA610C
Cooling Capacity (config. attr.)	~330W (284 kcal/h) at 10°C	~900W (770 kcal/h) at 10°C
Circulation Method	External sealed circulation via circulation pump
Operating Temperature Range	-10°C to 80°C
Temperature Control Accuracy	±0.1°C
Temperature Display Resolution	0.1°C
Temperature Control	PID control
Temperature Sensor	Temperature controller: Pt resistance thermometer; Over-temp protection: K-type thermocouple
Temperature Setting/Display	Digital setting, digital display
Refrigeration Type	Air-cooled
Refrigeration Unit Power / Refrigerant	300W, R404A	675W, R404A
Circulation Pump Type	Magnetic pump
Circulation Pump Power	45W	65W
System Circulation — Max Flow Rate (50/60Hz)	8.9/10.3 L/min	16.4/18.3 L/min
System Circulation — Pump Capacity Flow (50/60Hz)	15/17 L/min	22.0/25.0 L/min
System Circulation — Max Head (50/60Hz)	6.6/9.0 m	9.7/13 m
System Circulation — Pump Capacity Head (50/60Hz)	8.0/11.0 m	10.0/13.5 m
Heater	Stainless steel heating tube, 1.0 kW	Stainless steel heating tube, 2.5 kW
Cooling Tube Material	Nickel-plated copper
External Circulation Port	Rc3/8" (CFA301 standard tower fitting)
Ambient Operating Temp Range	5–35°C
Safety Devices	Self-diagnostic function, overcurrent/leakage protection switch, refrigeration overload protector, refrigeration pressure detection, refrigeration protection delay timer, anti-dry-run float switch, circulation pump protection bypass, auto over-temp protection, over-temp protector
Other Functions	Drain valve, condenser filter screen, RS485 external communication, refrigeration pressure indicator, key lock, deviation correction, temperature output terminal (4–20mA)
Tank Dimensions	W250 × D315 × H180 mm	Inner diameter 300 × H236 mm
Tank Material	Stainless steel
Tank Capacity	~13L	~16L
Power Supply (50/60Hz)	AC220V, 8A	AC220V, 17A
External Dimensions (W×D×H)	380 × 565 × 720 mm	420 × 565 × 1050 mm
Weight	~60 kg	~77 kg
Standard Accessories	Drain tube, overflow tube
