Explosion-proof precision constant temperature chamber

AED 21,485.00

Availability:In stock

Only %1 left

Explosion-Proof Precision Constant Temperature Chamber – forced-air circulation with pressure relief safety door (explosion vent), door interlock mechanism, and explosion detection switch. 3-segment PID, 30-step programmable operation, SSR drive. Capacities 91L/216L, max 260°C (DF) or 360°C (DH). AC220V. Ideal for hazardous sample testing.

BrandYamato Scientific

More Information
Product Name	Explosion-proof precision constant temperature chamber
Weight	1.000000

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Technical Data
Specification	DF411SC	DF611SC	DH411SC	DH611SC
System	Forced-air circulation + ventilation
Temp. control range	RT+10~260°C	RT+10~260°C	RT+10~360°C	RT+10~360°C
GB standard — temp. fluctuation	±0.2°C (at 260°C)		±0.3°C (at 360°C)
GB standard — temp. deviation	±2°C (at 100°C), ±3°C (at 200°C), ±4°C (at 260°C)		±2°C (at 100°C), ±3°C (at 200°C), ±4°C (at 300°C), ±5°C (at 360°C)
JTM standard — temp. control accuracy	±0.1°C (at 260°C)		±0.2°C (at 360°C)
JTM standard — temp. distribution accuracy	±2.5°C (at 260°C)		±3.0°C (at 360°C)
Time to max temp.	~60 min (to 260°C)		~80 min (to 360°C)
Interior	Stainless steel plate
Exterior	Cold-rolled steel plate, chemical-resistant baked coating
Insulation	Glass fiber	Glass fiber	Rock wool	Rock wool
Heater	Finned stainless steel heating tube
Heater capacity	2.1kW	3.0kW	2.7kW	3.75kW
Blower fan/motor	Axial flow fan, motor 20W×1
Cable hole	φ30mm (rear)
Special safety mechanisms	Pressure relief safety door (explosion vent) + exhaust damper (manual)
Door interlock	Door lock mechanism — operation only possible when door locked
Explosion detection	Explosion detection switch in chamber — interrupts operation when triggered
Temp. control method	3-segment PID control
Temp. setting method	Dedicated operation function menu key + ▲▼ keys, digital setting
Temp. display	Measured temp: Green 4-digit LED / Set temp: Red 4-digit LED
Timer	1min~99hr59min & 100~999hr50min (with timer wait function)
Operation modes	Constant value, program, auto-stop, auto-start
Program mode	3-segment 30-step (30 steps×1 / 15 steps×2 / 10 steps×3)
Additional functions	Calibration offset, key lock, power outage compensation
Heater circuit control	SSR drive
Sensor	K-type thermocouple (temp. control + over-temp protection)
Safety devices	Self-diagnostic circuit (temp. sensor abnormality, heater wire break, auto over-temp prevention, SSR short-circuit), over-temp protector, overcurrent leakage protection switch, key lock, pressure relief safety door (explosion vent), explosion detection switch
Internal dims (W×D×H)	450×450×450mm	600×600×600mm	450×450×450mm	600×600×600mm
External dims (W×D×H)	1050×630×1250mm	1200×780×1400mm	1050×630×1250mm	1200×780×1400mm
Internal capacity	91L	216L	91L	216L
Shelf load capacity	30kg/level
Shelf levels/pitch	9 levels/45mm	9 levels/60mm	9 levels/45mm	9 levels/60mm
Power source (50/60Hz)	AC220V, 10A	AC220V, 14A	AC220V, 13A	AC220V, 17.5A
Weight	~78kg	~109kg	~78kg	~109kg
Shelf boards (SS wire)	2 pieces	3 pieces	2 pieces	3 pieces
Shelf brackets	4 pieces	6 pieces	4 pieces	6 pieces
Optional stand	OP42C	OP62C	OP42C	OP62C
Other options	Shelf board (1 board incl. 2 brackets), cable hole (30/50mm), mini printer, recorder, combined alarm lamp (standby/running/fault), observation window, external communication (RS485), temp. output terminal (4-20mA), external alarm output terminal, time-up output terminal, centralized monitoring software, touchscreen controller
