Low-temperature incubator/Thermostat

AED 28,765.00

Availability:In stock

SKU

LBX-YMT-0406

The INC820 Low Temperature Incubator combines a 150L incubator and 143L refrigerated chamber in one space-saving unit. Featuring precise temperature control, programmable operation, manual and automatic defrost functions, dual chamber flexibility, and advanced safety protection, it is ideal for microbiology, pharmaceutical, biotechnology, and research laboratory applications.

BrandYamato Scientific

More Information
Product Name	Low-temperature incubator/Thermostat
Weight	1.000000
Part No.	LBX-YMT-0406
Supplier Item Code	INC820

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Technical Data
Product Code	211210
Model	INC820
Basic configuration	Upper tank: thermostat Lower tank: low temperature thermostat
Upper method	Natural convection air jacket system
Top section: Performance, Temperature control range	(room temperature +5) ~80℃
Upper performance Temperature control accuracy	±0.5℃ (at 37℃)
Upper performance Temperature distribution accuracy	±1℃ (at 37℃)
Top section: Configuration and interior	stainless steel sheet
Upper section configuration: Cable holes	Inner diameter 30mm, right side of the main body
Upper section configuration: Exhaust vent	30mm (with damper) Two locations on the ceiling of the main unit
Top section: Configuration Controller	VS3 type constant-value operation temperature controller
Upper section: Operating functions	Constant value operation, quick auto-stop operation, auto-stop operation, auto-start operation
Top section Standard internal dimensions	600 x 530 x 500 mm
Top section: Standard internal volume	150L
Top section accessories: shelf board/shelf brackets	Stainless steel perforated metal, 2 pieces/4 pieces
Lower method	forced air circulation
Lower section: Performance, Temperature control range	4℃～50℃
Lower performance Temperature control accuracy	±0.3℃ (during continuous operation of the refrigerator)
Lower performance Temperature distribution accuracy	±1°C (at 37°C, during continuous operation of the refrigerator)
Lower section: Configuration and interior	stainless steel sheet
Lower section configuration: Refrigeration unit	Air-cooled 250W
Lower section: Components refrigerant	R404A
Lower section: Configuration of the refrigerator operating range	Setting below 44℃
Lower section configuration: Defrosting operation	Manual and cycle
Lower section configuration: Cable holes	Inner diameter 50mm, right side of the main body
Lower section configuration: Controller	VS4 type programmable temperature controller
Lower section: Operating functions	Program operation (30 steps x 1, 15 steps x 2, 10 steps x 3), constant value operation, quick auto-stop operation, auto-stop operation, auto-start operation
Lower section Standard internal dimensions	600 x 477 x 500 mm
Lower berth Specifications Internal volume	143L
Lower section accessories: shelf board/shelf brackets	Stainless steel perforated metal, 3 sheets/6 pieces
Common Configuration Sensors	Platinum resistance thermometer Pt100Ω
Common Configuration Options	RS485 terminal, recorder connection terminal, alarm terminal
Common safety equipment	Self-diagnostic functions ( temperature sensor malfunction, heater wire breakage, SSR short circuit, automatic over-temperature protection function, etc.), key lock, over-temperature protector, overcurrent leakage circuit breaker.
Common standard: Number of shelves/pitch	13 steps/30mm
Standard shelf load capacity	Approximately 15 kg/sheet
Common accessories: Door key	2 pieces x 2 sets
Internal volume	Upper compartment: 150L Lower compartment: 143L
External dimensions (width x depth x height)	710 x 645 x 1792 mm
Power capacity	AC100V 14A
breaker capacity and power supply equipment capacity 15A
weight	160kg
