Vertical pressure steam sterilizer

AED 19,736.00

Availability:In stock

Only %1 left

Yamato CE-Certified SN/SQ-C Series Vertical Steam Sterilizer – export-grade autoclave for international lab use. Operates 45~135°C with 3mm mirror-finish stainless chamber, 20-year design life, and Class I pressure vessel certification. Available in AC115V/AC220V, 20L–47.5L capacities. PID control, cooling fan, and comprehensive safety interlocks standard equipped.

BrandYamato Scientific

More Information
Product Name	Vertical pressure steam sterilizer
Weight	1.000000

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Technical Data
Specification	SN200C	SN210C	SN300C	SN310C	SN500C	SN510C	SQ500C	SQ510C
Product code	213800	213801	213802	213803	213804	213805	213806	213807
Certification	CE
Voltage	AC115V	AC220V	AC115V	AC220V	AC115V	AC220V	AC115V	AC220V
System	Automatic high-pressure steam sterilization
Operating temp. range	45~135°C (45~80°C Preheating / 45~60°C Heat-retention / 65~100°C Solution / 105~135°C Sterilization)
Temp. display unit	0.1°C
Max. working pressure	0.255 MPa
Lid structure	Manual upward-opening type with safety interlock
Chamber material	3mm corrosion-resistant stainless steel, mirror-finish
Design service life	20 years
Design pressure	0.42 MPa
Design temperature	151°C
Heater	600W×2	600W×2	800W×2	800W×2	950W×2	950W×2	1000W×2	1000W×2
Exhaust valve	Quick exhaust + slow release, 1 each
Optional ports	Sample sensor port (1/4") / Recorder sensor port (1/4") / Pressure gauge port (on solenoid valve pipe)
Cooling fan	Axial flow fan motor
Temp. control	PID control by microcomputer / digital setting via ▲▼ keys
Timer	0 or 1 min~99hr59min, resolution: 1 min
Operation modes	Instrument sterilization / Liquid sterilization / Sterilization & keep warm / Melting & keep warm / Manual mode
Other functions	Key lock, presetting, memory, preheating, forced cooling, optional sample temp. sensor, pattern lock, 20 error log saving, accumulated runtime display, time display, ON/OFF beep setting
Safety devices	Sensor abnormality, SSR short-circuit, heater wire break, dry-run prevention (liquid expansion type), cooling water absence alarm, lid lock abnormality, memory error, pressure relief valve (0.255 MPa)
Pressure vessel class	Class I pressure vessel
Internal capacity	20L	20L	32L	32L	47L	47L	47.5L	47.5L
Chamber dims (ID×D)	ID240×D445mm	same	ID300×D445mm	same	ID300×D665mm	same	ID370×D442mm	same
External dims (W×D×H)	400×530×840mm	same	460×590×848mm	same	460×590×1058mm	same	520×660×846mm	same
Weight	~65kg	~65kg	~75kg	~75kg	~85kg	~85kg	~95kg	~95kg
Included baskets	OSM-60 (φ209×D204mm) ×2	same	OSM-70 (φ266×D204mm) ×2	same	OSM-70 (φ266×D204mm) ×3	same	OSQ-90 (φ332×D195.5mm) ×2	same
Other accessories	Steam cup ×1, drain bottle ×1, drain board ×1, filter ×1, manual, warranty
Optional accessories	Sample temp. sensor, chamber temp. sensor, recorder, pressure gauge, external alarm output, temp. output (4-20mA), time-up output terminal, biosafety filtration system, standard/tall basket
