Constant Temperature Oven, Rapid heat & Cool, Forced Convection

AED 17,706.00

Availability:In stock

Only %1 left

Rapid Heating and Cooling Oven – fast temperature rise/fall (25→260°C in 45 min, 260→50°C in 50 min) boosts productivity. Horizontal airflow ensures accurate performance under load, ideal for magazine rack sample processing. Multi-voltage (200–220V), low-silicone versions available. Perfect for high-throughput lab environments.

BrandYamato Scientific

More Information
Product Name	Constant Temperature Oven, Rapid heat & Cool, Forced Convection
Weight	1.000000

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Specification	DKG611	DKG611V	DKG811	DKG811V
Product Code	212896	212897	212898	212899
System	Forced Convection Circulation Type (with Exhaust Damper)
Temperature Control Range	Room Temperature +30°C to 260°C
Temperature Fluctuation	JTM K05 ±0.5°C at 260°C	JTM K05 ±0.5°C at 260°C	JIS ±2°C at 260°C	JIS ±2°C at 260°C
Temperature Variation	JIS ±1°C at 260°C	JTM K05 ±2.0°C at 200°C / ±2.5°C at 260°C	JIS ±15°C at 260°C	JIS ±15°C at 260°C
Temperature Distribution Accuracy	JIS ±10°C at 260°C
Maximum Temperature Rise Time	≤45 min (25°C → 260°C)	≤45 min (25°C → 260°C)	≤50 min (25°C → 260°C)	≤50 min (25°C → 260°C)
Temperature Fall Time	Approx. 40 min (260°C → 50°C)	Approx. 40 min (260°C → 50°C)	≤50 min (260°C → 50°C)	≤50 min (260°C → 50°C)
Interior Material	Stainless Steel Plate
Door Packing	Silicone Rubber	Fluorine Rubber	Silicone Rubber	Fluorine Rubber
Heater Capacity	2.6–3.15 kW	2.6–3.15 kW	3.6–4.36 kW	3.6–4.36 kW
Cable Holes	Inner Diameter 30 mm × 1 (Right Side)
Air Inlet	Manual Open / Close via Heater Partition
Exhaust Port	Ø80 mm (Body Bottom Rear)
Exhaust Damper	Manual Link-Type Exhaust Damper
Controller Type	VS6 Type (PID Control)
Operation Modes	Constant Value, Program Operation, Quick Auto-Stop, Auto-Stop, Auto-Start, Programmed Auto-Stop
Program Modes	6 Patterns (PrG1: 30 Steps; PrG2–PrG5: 15 Steps Each; PrG6: 4–10 Steps), Step Weight Function, Repeat Function, Step Weight Stop Function
Convenient Functions	Program Reservation Start Offset, Setting Lock Function, Power Outage Recovery Mode Selection Function
Safety Devices	Self-Diagnostic Function (Auto Overcurrent Prevention), Temperature Sensor Abnormality, Heater Wire Break, SSR Short Circuit, Memory Error, Internal Communication Abnormality, Set Temperature Abnormality, Overheat Prevention Relay, Door Switch, Temperature Fuse, External Alarm Output Terminal
Internal Dimensions (W × D × H)	500 × 600 × 500 mm	500 × 600 × 500 mm	600 × 600 × 1000 mm	600 × 600 × 1000 mm
External Dimensions (W × D × H)	770 × 696 (846) × 985 mm	770 × 696 (846) × 985 mm	600 × 696 (846) × 1674 mm	600 × 696 (846) × 1674 mm
Internal Capacity	150 L	150 L	300 L	300 L
Shelf Positions / Maximum Shelf Load	7 Levels, 60 kg	7 Levels, 60 kg	15 Levels, 60 kg	15 Levels, 60 kg
Shelf Board Load Capacity	15 kg per Shelf (35 kg Total)	15 kg per Shelf (35 kg Total)	15 kg per Shelf (75 kg Total)	15 kg per Shelf (75 kg Total)
Power Source (50/60 Hz)	1Ø AC200–220V, 13.5–15.0 A	1Ø AC200–220V, 13.5–15.0 A	1Ø AC200–220V, 18.5–20.5 A	1Ø AC200–220V, 18.5–20.5 A
Breaker Capacity	20 A	20 A	30 A	30 A
Weight	Approx. 110 kg	Approx. 110 kg	Approx. 155 kg	Approx. 155 kg
Standard Accessories	2 Shelf Boards, Shelf Brackets (4 Sets)	2 Shelf Boards, Shelf Brackets (4 Sets)	4 Shelf Boards, Shelf Brackets (8 pcs)	4 Shelf Boards, Shelf Brackets (8 pcs)
