Rectangular vacuum dryer

AED 15,089.00

Availability:In stock

Only %1 left

The DP Series Rectangular Vacuum Dryers provide high-capacity vacuum drying for large components and production environments. Featuring programmable operation, PID temperature control, spacious drying chambers, integrated vacuum pump storage, and advanced safety systems, these dryers ensure efficient, reliable, and precise drying performance for industrial, research, and custom manufacturing applications.

BrandYamato Scientific

More Information
Product Name	Rectangular vacuum dryer
Weight	1.000000

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Technical Data
Specification	DP810	DP1030
Type	Rectangular Vacuum Dryer	Rectangular Vacuum Dryer
Drying Method	Reduced Pressure & Wall Heating	Reduced Pressure & Wall Heating
Temperature Range	40–200°C	40–200°C
Operating Pressure Range	100–0.1 kPa (760–1 Torr)	100–0.1 kPa (760–1 Torr)
Temperature Control Accuracy	±1°C (at 200°C)	±1°C (at 200°C)
Temperature Control Method	Microcomputer PID Control	Microcomputer PID Control
Heater Control	Triac Zero Cross Method	Triac Zero Cross Method
Sensor	Double K-Type Thermocouple	Double K-Type Thermocouple
Interior Material	Stainless Steel	Stainless Steel
Exterior Material	Chromium-Free Electro-Galvanized Steel, Baked Finish	Chromium-Free Electro-Galvanized Steel, Baked Finish
Operation Functions	Constant Value, Quick Auto-Stop, Auto-Start, Auto-Stop, Program Operation	Constant Value, Quick Auto-Stop, Auto-Start, Auto-Stop, Program Operation
Program Capacity	Up to 99 Steps, 99 Patterns	Up to 99 Steps, 99 Patterns
Safety Features	Self-Diagnostics, Independent Overheat Protection, Key Lock, Leakage Circuit Breaker	Self-Diagnostics, Independent Overheat Protection, Key Lock, Leakage Circuit Breaker
Heater Capacity	6.5 kW	14.4 kW
Internal Dimensions (W×D×H)	800 × 800 × 800 mm	1000 × 1000 × 1000 mm
Shelf Quantity	2	4
Shelf Load Capacity	15 kg/Shelf	15 kg/Shelf
Power Supply	Single-Phase AC 200V, 33A	Three-Phase AC 200V, 50A
Weight	600 kg	1000 kg
