Cooling water circulation device

AED 15,463.00

Availability:In stock

Only %1 left

Cooling Water Circulation Device — open-system circulator with ON-OFF refrigeration control, adjustable flow valve, and flow-rate monitoring sensor. Features auto-stop protection, deviation correction, power-failure compensation, and temperature output terminal. Air-cooled with R404A refrigerant, magnetic pump. Three cooling capacities available for tanks of varying size.

BrandYamato Scientific

More Information
Product Name	Cooling water circulation device
Weight	1.000000

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Technical Data
Specification	CLS312C	CLS411C	CLS610C
Cooling Capacity (config. attr.)	~450W (387 kcal/h) at 15°C	~570W (490 kcal/h) at 15°C	~820W (705 kcal/h) at 15°C
Circulation Method	External open circulation via circulation pump
Operating Temperature Range	-10°C to room temp	-15°C to room temp	-15°C to room temp
Temperature Control Accuracy	±1.5 to ±2°C
Temperature Control	Refrigeration unit ON-OFF control
Temperature Sensor	T-type thermocouple
Temperature Setting/Display	Digital setting, digital display
Refrigeration Type	Air-cooled
Refrigeration Unit Power / Refrigerant	200W, R404A	350W, R404A	600W, R404A
Circulation Pump Type	Magnetic pump
System Circulation — Max Flow Rate (50/60Hz)	5.4/6.2 L/min	5.4/6.3 L/min	6.7/7.8 L/min
System Circulation — Pump Capacity Flow (50/60Hz)	10.0/11.0 L/min	10.0/11.0 L/min	15.0/17.0 L/min
System Circulation — Max Head (50/60Hz)	3.5/5.0 m	3.7/5.3 m	6.2/8.7 m
System Circulation — Pump Capacity Head (50/60Hz)	4.9/6.9 m	4.9/6.9 m	8.0/11.0 m
Cooling Tube Material	Nickel-plated copper
External Circulation Port	Water out & return, both Ø13mm outer diameter
Ambient Operating Temp Range	5–30°C
Safety Devices	Self-diagnostic function, overcurrent/leakage protection switch, key lock, power-failure compensation, flow monitoring, refrigeration unit monitoring, refrigeration protection delay timer, flow anomaly detection, high-pressure anomaly detection
Other Functions	Flow regulating valve, drain valve, condenser filter screen, temperature output terminal, deviation correction, key lock, power-failure compensation
Tank Dimensions	Inner diameter 120 × depth 200 mm	Inner diameter 150 × depth 200 mm
Tank Material	Stainless steel	Same	Same
Tank Capacity	1.5L	3L	3L
Power Supply (50/60Hz)	AC220V, 3A	AC220V, 3.5A	AC220V, 5.5A
External Dimensions (W×D×H)	410 × 460 × 550 mm	380 × 513 × 725 mm	380 × 615 × 725 mm
Weight	~40 kg	~45 kg	~60 kg
Standard Accessories	Circulation insulation tube ×1, pump circulation tube ×1, hose clamps ×4, drain tube ×1
