High-temperature constant temperature incubator

AED 5,750.00

Availability:In stock

Only %1 left

High-Temperature Constant Temperature Incubator — natural air-jacket convection incubator with PID control, room temp+5°C to 80°C range, double-door reinforced glass viewing. 3-segment/30-step programmable operation, self-diagnostic safety circuit, over-temp/leakage protection. Four capacity tiers from 97L to 567L with digital LED display.

BrandYamato Scientific

More Information
Product Name	High-temperature constant temperature incubator
Weight	1.000000

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Technical Data
Specification	IS412C	IS612C	IS812C	IS912C
Chamber Capacity (config. attr.)	97L	159L	318L	567L
Method	Air-flow natural convection
Operating Temperature Range	Room temp+5°C to 80°C
Temp. Fluctuation (GB)	±0.5°C (at 37°C)
Temp. Uniformity (GB)	±1.5°C (at 37°C)
Temp. Control Accuracy (JTM)	±0.2°C (at 37°C)
Temp. Distribution Accuracy (JTM)	±1.0°C (at 37°C)
Interior Material	Stainless steel plate
Exterior Material	Cold-rolled steel, chemical-resistant coating
Insulation	Glass fiber
Heater	Nickel-chromium alloy heating wire
Heater Power	0.3 kW	0.4 kW	0.7 kW	2.2 kW
Exhaust Port	Ø30mm × 2, top-mounted		Ø30mm × 2, left & right (one each)
Temperature Control Method	PID control
Temperature Setting Method	Dedicated function menu key + up/down keys, digital
Temperature Display	Measured: green 4-digit LED; Set: red 4-digit LED
Timer	1min–99h59min and 100–999h50min (with timed-wait)
Operating Functions	Fixed-value, program, auto-stop, auto-start
Program Mode	3-segment/30-step (30×1, 15×2, 10×3)
Additional Functions	Deviation correction, key lock, power-failure compensation
Sensor	Pt resistance thermometer (control) + K-type thermocouple (over-temp protection)
Safety Devices	Self-diagnostic circuit (sensor fault, SSR short-circuit, heater wire break, auto over-temp prevention), key lock, over-temp protector, overcurrent/leakage protection switch
Internal Dimensions (W×D×H)	450×480×450mm	600×530×500mm	600×530×1000mm	1070×530×1000mm
External Dimensions (W×D×H)	560×606×820mm	710×656×870mm	710×656×1619mm	1180×655×1619mm
Internal Volume	97L	159L	318L	567L
Shelf Load Capacity	~15 kg/shelf	Same	Same	Same
Number of Shelves	11	13	29	29×2
Shelf Spacing	30mm
Power Supply (50/60Hz)	AC220V, 1.5A	AC220V, 2A	AC220V, 3.5A	AC220V, 6.5A
Weight	~45 kg	~65 kg	~102 kg	~166 kg
Standard Accessories — Shelves	Stainless steel perforated shelf ×2	Same ×2	×4	×8
Standard Accessories — Shelf Supports	×4	Same	×8	×16
Optional: Stand	ONS61C	—	—	—
Optional: Stacking Bracket	OD40C	OD60C	—	—
Other Optional Accessories	Additional shelf (1 shelf incl. 2 supports), wire port (30/50mm), mini printer, data recorder, combination warning light (standby/running/fault), observation window, RS485 external communication, temperature output terminal (4–20mA), external alarm output terminal, time-reached output terminal, centralized monitoring software, touchscreen controller
