Constant temperature drying oven

AED 2,953.00

Availability:In stock

Only %1 left

Natural Convection Drying Oven – economical, entry-level lab oven heating up to 280°C. Microcomputer PID control, digital sub-menu settings, K-thermocouple sensing, and hydraulic over-temperature protection. Available in 28L–153L capacities, AC100V power. Ideal for basic drying, curing, and heat treatment on a budget.

BrandYamato Scientific

More Information
Product Name	Constant temperature drying oven
Weight	1.000000

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Technical Data
Specification	DY301	DY401	DY601
Product code	212030	212050	212069
System	Natural convection
Temp. control range*¹	RT+10~280°C
*Temp. fluctuation (JIS C60068-3-5:2020)¹	±2°C (at 280°C, exhaust fully closed)
*Temp. gradient (JIS C60068-3-5:2020)¹	30°C (at 280°C, exhaust fully closed)
*Temp. rise rate (JIS C60068-3-5:2020)²	6.9°C/min	4.3°C/min	1.7°C/min
*Time to max temp. (reference)²	~60 min	~70 min	~120 min
Exhaust port	φ34mm × 2 (ceiling)
Heater	Wire heater, 450W×2	Wire heater, 450W×2	Wire heater, 680W×2
Control method	PID control of heater output by microcomputer
Setting method	Digital, sub-menu key + ▼▲ keys
Operation modes	Constant value, auto-stop, quick auto-stop, auto-start
Sensor	K-type thermocouple
Additional functions	Calibration offset
Safety devices	Controller self-diagnostic (temp sensor abnormality, memory abnormality, auto over-temp prevention, measured temp abnormality)
Protection devices	Leakage breaker, hydraulic independent over-temp protection
External dims (W×D×H)	400×440×630mm	550×540×730mm	700×640×830mm
Internal dims (W×D×H)	300×310×300mm	450×410×400mm	600×510×500mm
Internal capacity	28L	74L	153L
Weight	~23kg	~38kg	~56kg
Power source (50/60Hz)	100V, 9.5A	100V, 14A	100V, 14A
Accessories	2× shelf boards (~15kg/board load), manual, warranty card
